PIRmax HR Panel

PIRmax is a modified PIR (Polyisocyanurate) rigid thermal panel that can be used in many applications. Pirmax PIR is the next generation in high performing insulators for commercial and residential developments.

Designed to achieve excellent thermal value where minimal cavity is required. It has the highest thermal value of any PIR insulation product available, due to the low Thermal Conductivity, giving buildings continued thermal efficiency throughout its life span.

PIRmax PIR rigid panel is a light weight closed cell Polyisocyanurate foam core panel. Easy to handle and allows fast fixing to any application. Australian Made, Pirmax is fully compliant to the Australian National Construction Code.

PIRmax HRP Panel

PIRmax HRP is a modified PIR (Polyisocyanurate) rigid thermoset insulation laminated with 10mm plasterboard from Knauf. PIRmax HRP consists of one side tapered edge gypsum based 10mm plasterboard and foil on the reverse side adhesively bonded to the PIR core.

Alternative linings, such as cement sheet, can also be used upon request. PIRmax HRP achieve excellent thermal value where minimal cavity is required giving buildings continued thermal to designed efficiency throughout its life span.

Photos

Copyright ©2006 RM Industries| Hosting by Enetica.com.au

Compliance

Complies to AS/NZ 4859.1

NCC/BCA Compliant

Group Classification AS ISO 9705:2003           Group 1 Lining

Group Classification AS/NZS 3837:1998          Group 1 Lining

AS 1530.3   Regulatory Indices:                       Ignitability Index 0   Range 0-20

                                                                        Spread of Flame Index 0   Range 0-10

                                                                        Heat Evolved Index 0   Range 0-10

                                                                        Smoke Developed Index 1 Range 0-10

Compressive Strength                                     >125 (kPa)

Water Vapour Resistivity                                  >100 (MNs/gm)

Edge Treatment                                                Square Edge

PIRmax PIR Panels produces a range of innovative insulation solutions giving the building/construction industry a product which has been tested to meet the stringent requirements of the Building Codes Australian (BCA) and National Construction Code (NCC).
